Octree-based adaptive mesh refinement and the shifted boundary method for efficient fluid dynamics simulations

Cheng-Hau Yang; Guglielmo Scovazzi; Adarsh Krishnamurthy; Baskar Ganapathysubramanian

doi:10.3934/acse.2025012

Article Contents

June 2025, Volume 4, 57-84. Doi: 10.3934/acse.2025012

This volume Previous Article Enhanced low-dose CT image reconstruction by domain and task shifting gaussian denoisers Next Article Anderson acceleration for perturbed Newton methods

Octree-based adaptive mesh refinement and the shifted boundary method for efficient fluid dynamics simulations

1.
Department of Mechanical Engineering, Iowa State University, Ames, IA 50011, USA
2.
Department of Civil and Environmental Engineering, Duke University, Durham, NC 27708, USA

^*Corresponding author: Baskar Ganapathysubramanian
^*Corresponding author: Baskar Ganapathysubramanian

Received: December 2024

Revised: March 2025

Published online: April 15, 2025

Abstract / Introduction Full Text(HTML) Figure(13) / Table(5) Related Papers Cited by

Abstract

This paper presents an adaptive mesh refinement (AMR) framework integrated with the shifted boundary method (SBM) for incompressible flow and coupled thermal-flow simulations. Our framework leverages octree-based AMR, enabling hierarchical and dynamic mesh refinement driven by vorticity magnitude. This strategy enables capturing complex vorticity structures and steep thermal gradients while significantly reducing computational costs compared to traditional uniform refinement approaches, particularly for flows around complex geometries. The octree-based architecture ensures efficient data management, including robust intergrid transfer and load balancing, which is critical for scalability in distributed-memory environments. Dynamic mesh adaptivity is demonstrated for complex geometries where achieving ideal refinement is often non-trivial due to the irregular boundaries. SBM enhances this adaptability by accurately enforcing boundary conditions on intricate and non-conformal geometries without requiring boundary-fitted meshes. Together, these methods address longstanding challenges in computational fluid dynamics, providing a resource-efficient yet accurate approach for capturing critical flow and thermal features. The utility of the framework is demonstrated through numerical experiments, showcasing its ability to adapt dynamically to evolving flow and thermal patterns in diverse and challenging geometries.

Keywords:

Mathematics Subject Classification: Primary: 58F15, 58F17; Secondary: 53C35.

Citation:

FullText(HTML)

Figure 1. The surrogate domain, its boundary, and the distance vector $ \boldsymbol{d} $

Download: Full-size image PowerPoint slide

Figure 2. Flow past a two-dimensional circular cylinder at $ Re = 100 $: mesh with AMR vorticity contours are shown in the top pane, while mesh refinement levels are shown in the bottom pane. The figure highlights the refined mesh regions around the cylinder due to AMR, which optimally reduces mesh elements while retaining flow features

Download: Full-size image PowerPoint slide

Figure 3. Flow past a two-dimensional circular cylinder at $ Re = 100 $: mesh with wake refinement (refinement level 12, mesh size $ 30 \times 2^{-12} $)

Download: Full-size image PowerPoint slide

Figure 4. Flow past a two-dimensional circular cylinder at $ Re = 100 $: history of the number of mesh nodes for AMR versus a regular grid with uniform mesh refinement in the wake region (indicated by the white box in Figure 2b). The significant reduction in node count achieved by AMR emphasizes computational efficiency

Download: Full-size image PowerPoint slide

Figure 5. Lid-driven cavity flow with complex internal geometries: velocity profiles. The first row of pictures displays an overlay of the vorticity with the AMR mesh, while the second row displays velocity profiles around a cat-shaped obstacle, comparing results between the SBM and a BFM. These simulations, conducted at Reynolds numbers of $Re = 50 $, $Re = 500 $, and $Re = 1000 $, illustrate how both the obstacle shape and Reynolds number affect the flow dynamics

Download: Full-size image PowerPoint slide

Figure 6. Lid-driven cavity flow with complex internal geometries: Plot of the y-direction velocity ($ v $) along $ y = 0.5 $, with $ x $ ranging from 0.06 to 0.2 inside the flow chamber. Comparison of AMR-SBM and SBM at different uniform refinement levels. AMR-SBM refers to simulations using dynamic AMR with SBM, while SBM represents simulations with uniform meshes. AMR-SBM outperforms most SBM simulations with uniform meshes, except for the case with a uniform mesh refinement level of $ 9 $

Download: Full-size image PowerPoint slide

Figure 7. Mixed convection inside a lid-driven cavity: Velocity magnitude distribution (first row of plots) and temperature distribution (second row of plots), for varying Richardson numbers ($ Ri $). These plots demonstrates how changes in $ Ri $ affect the temperature field, with the AMR approach capturing all essential temperature gradients and flow patterns

Download: Full-size image PowerPoint slide

Figure 8. Mixed convection inside a lid-driven cavity: temperature distribution for varying Richardson numbers ($ Ri $). The figure demonstrates how changes in $ Ri $ affect the temperature field, with the AMR approach capturing essential temperature gradients

Download: Full-size image PowerPoint slide

Figure 9. Mixed convection inside a lid-driven cavity: Temperature distribution for different Richardson numbers ($ Ri $). This figure compares results obtained using the SBM with AMR and uniform meshes. The term AMR-SBM refers to simulations performed with dynamic AMR and SBM, whereas SBM denotes simulations using SBM with uniform octree meshes

Download: Full-size image PowerPoint slide

Figure 10. Natural convection past a star-shaped domain: vorticity contours over time. The vorticity-based AMR allows for accurate tracking of vorticity at different non-dimensional times

Download: Full-size image PowerPoint slide

Figure 11. Natural convection past a star-shaped domain: temperature contours at various non-dimensional times. The AMR captures well the evolution of high thermal gradients over time

Download: Full-size image PowerPoint slide

Figure 12. Visualization of the initial mesh refinement setup for the flow past a sphere, highlighting the distribution before adaptive refinement is introduced

Download: Full-size image PowerPoint slide

Figure 13. Flow past a sphere at $ Re = 300 $. (a) and (b) illustrate octree element volumes and the Q-criterion respectively, while (c) compares the centerline average streamwise velocity profile with benchmark data [84]

Download: Full-size image PowerPoint slide

Table 1. Flow past a two-dimensional circular cylinder at $ Re = 100 $: comparison of drag coefficient ($ C_d $) and Strouhal number ($ St $). The results of SBM with AMR are consistent with the literature, confirming the accuracy of the proposed approach for different mesh refinement levels

Study	$ C_d $	$ St $
Liu et al. [52]	1.350	0.1650
Lai et al. [49]	1.447	0.1650
Uhlmann [85]	1.453	0.1690
Yang et al. [98]	1.393	0.1650
Kamensky et al. [40]	1.386	0.1700
Current (finest element size = $ 30/2^{12} $)	1.401	0.1709
Current (finest element size = $ 30/2^{13} $)	1.404	0.1707
Current (finest element size = $ 30/2^{14} $)	1.405	0.1707

| Show Table

DownLoad: CSV

Table 2. Flow past a two-dimensional circular cylinder at $ Re = 100 $: Comparison of the drag coefficient ($ C_d $) and Strouhal number ($ St $). The term AMR-SBM refers to simulations conducted with dynamic AMR and the SBM, while SBM denotes simulations using SBM with local mesh refinement. Both AMR-SBM and SBM simulations are performed with a base refinement level of 5 and a boundary layer refinement level of 12 near the circular disk. For SBM (without AMR), we locally refine the region up to $ level_{wake} $ just upstream of the circular disk and throughout the wake region, as shown by the white box in Figure 2b. Below, we present SBM simulations with $ level_{wake} $ set to 10, 11, and 12, and compare the results with AMR-SBM. We treat the SBM simulation with the highest refinement level in the upstream and wake region as the ground truth and use it to calculate $ Error_{C_d} = \frac{|C_d - C_d^{\text{ground truth}|}}{|C_d^{\text{ground truth}}|} $ and $ Error_{St} = \frac{|St - St^{\text{ground truth}}|}{|St^{\text{ground truth}}|} $

Study	Highest Mesh Nodes	$ C_d $	$ St $	$ Error_{C_d} $	$ Error_{St} $
AMR-SBM	75464	1.401	0.1709	0.214%	0.0%
SBM ($ level_{wake} = 9 $)	29053	1.507	0.1685	7.336%	1.404%
SBM ($ level_{wake} = 10 $)	101694	1.411	0.1717	0.499%	0.468%
SBM ($ level_{wake} = 11 $)	389987	1.410	0.1717	0.427%	0.468%
SBM ($ level_{wake} = 12 $)	1544191	1.404	0.1709	0.0%	0.0%

| Show Table

DownLoad: CSV

Table 3. Lid-driven cavity flow with complex internal geometries: grid size comparison (in terms of mesh nodes) for uniform mesh versus AMR

Reynolds Number	Uniform Mesh	AMR Mesh	Compression Ratio
50	238100	34019	6.99
500		34487	6.90
1000		34676	6.87

| Show Table

DownLoad: CSV

Table 4. Mixed convection inside a lid-driven cavity: grid size comparison (in terms of mesh nodes) for uniform mesh versus AMR

Richardson number	Uniform Mesh	AMR Mesh	Compression Ratio
0.01	14780	4252	3.48
1		5237	2.82
5		9430	1.57

| Show Table

DownLoad: CSV

Table 5. Flow past a sphere at $ Re = 300 $: comparison of the drag coefficient ($ C_d $) and Strouhal number ($ St $) against various references. The proposed combined SBM-AMR approach compares well against previous experimental and computational studies

Study	Cd	St
Roos and Willmarth [69] (interpolated experiment value)	0.629	-
Le Clair et al. [51]	0.632	-
Johnson and Patel [38]	0.656	0.137
Marella et al. [57]	0.621	0.133
Vanella et al. [86]	0.634	0.132
Wang and Zhang [89]	0.680	0.135
Angelidis et al. [2]	0.665	0.132
Kang et al. [42]	0.663	0.134
Current	0.622	0.134

| Show Table

DownLoad: CSV
